4000MM AUTOMATIC GRINDING MACHINE FOR TANK BODY

[ MODEL:JT-CNC-4000 ]

CNC polishing machine for sheet metal
info
video
DOWNLOAD THE BROCHURE
Product Book
REQUEST INFO
Contact us
MACHINE DETAILS

4000MM  CNC GRINDING MACHINE FOR TANK BODY

With Siemens CNC control system,through set up starting and ending position to achieve automatic polishing solutions .

1.Full automatic with Siemens CNC controller

2.Polish tank shell and dished head both.

3.Polish inside and outside surface both

4. Double grinding head, one side for tank shell,another side for dished head.
5.Get matt ,bright and mirror surface

6. Belt and flap wheel can be exchanged

7.High efficiency with 10-12㎡/h

8.Best surface consistency

Polishing range:

Tank shell  φ:200-6000mm L:8000mm

Dish head  φ:400-6000mm H:1000mm

Machine main specification:

grinding motor power servo motor power boom moving distance column lift stroke
5.5kw 1kw 4000mm 1600mm

Package:plywood case

Delivery time:40 working days

Loading port: Shanghai/Ningbo/other China port

Warranty:12months

Installation&Commissioning: Overseas service is avaliable,Currently we have local service partner in Portugal,Turkey,India

cnc grinding machine factory

What other polishing machine we supply?

jotun polishing machine

  • cnc polishing machine
  • cnc polishing machine
  • cnc polishing machine
